(Plasmid #31601)


Item Catalog # Description Quantity Price (USD)
Plasmid 31601 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Khavari Lab
  • Backbone size (bp) 11100
  • Vector type
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol and Ampicillin
  • Growth Temperature
  • Growth Strain(s)
    ccdB Survival
  • Copy number
    Low Copy


  • Gene/Insert name

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ cloning site attR (not destroyed)
  • 3′ cloning site attR (not destroyed)
  • 5′ sequencing primer LZRS-F (TGGATACACGCCGCCCACGTG)
  • 3′ sequencing primer LZRS-R (ATCGTCGACCACTGTGCTGG)
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
  • Articles Citing this Plasmid
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    LZRS-Rfa was a gift from Paul Khavari (Addgene plasmid # 31601 ; ; RRID:Addgene_31601)
  • For your References section:

    Mek1 alters epidermal growth and differentiation. Scholl FA, Dumesic PA, Khavari PA. Cancer Res. 2004 Sep 1;64(17):6035-40 10.1158/0008-5472.CAN-04-0017 PubMed 15342384
