pCIBN-EYFP-hTRF2
(Plasmid #103804)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 103804 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pEGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3932
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CIBN-EYFP-hTRF2
  • Alt name
    N-terminus of CIB1
  • Species
    H. sapiens (human), A. thaliana (mustard weed)
  • Insert Size (bp)
    2807
  • Mutation
    hTRF2: deletion of amino acids 1-42 and 476 compared to NP_005643.2
  • Entrez Gene
    CIB1 (a.k.a. AT4G34530, T4L20.110, T4L20_110, cryptochrome-interacting basic-helix-loop-helix 1)
  • Entrez Gene
    TERF2 (a.k.a. TRBF2, TRF2)
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CMV-F
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

EGFP was cut out from the backbone (NheI/BamHI cuts)

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCIBN-EYFP-hTRF2 was a gift from Karsten Rippe (Addgene plasmid # 103804 ; http://n2t.net/addgene:103804 ; RRID:Addgene_103804)
  • For your References section:

    Real-time observation of light-controlled transcription in living cells. Rademacher A, Erdel F, Trojanowski J, Schumacher S, Rippe K. J Cell Sci. 2017 Dec 15;130(24):4213-4224. doi: 10.1242/jcs.205534. Epub 2017 Nov 9. 10.1242/jcs.205534 PubMed 29122982
