(Plasmid #109016)


Item Catalog # Description Quantity Price (USD)
Plasmid 109016 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Jacob Corn
  • Backbone size w/o insert (bp) 7860
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    TOM20MTS (MTS: mitochondria targeting signal)
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Entrez Gene
    TOMM20 (a.k.a. MAS20, MOM19, TOM20)
  • Promoter CMV promoter
  • Tag / Fusion Protein
    • mCherry-eGFP (C terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CTCGTTTAGTGAACCGTCAGATCG
  • 3′ sequencing primer CGTGAAGAATGTGCGAGACCC
  • (Common Sequencing Primers)

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    TOM20MTS-mCherry-EGFP-Tet-On was a gift from Jacob Corn (Addgene plasmid # 109016 ; ; RRID:Addgene_109016)
  • For your References section:

    Atlastins remodel the endoplasmic reticulum for selective autophagy. Liang JR, Lingeman E, Ahmed S, Corn JE. J Cell Biol. 2018 Aug 24. pii: jcb.201804185. doi: 10.1083/jcb.201804185. 10.1083/jcb.201804185 PubMed 30143524
