Purpose(Empty Backbone) Empty sgRNA expression plasmid
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||112915||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size (bp) 7500
Modifications to backboneModified to enable sgRNA insertion after BfuAI digestion. Also modified to include a 2kb stuffer sequence for easier gel purification of the fully digested vector.
Vector typeMammalian Expression, Lentiviral, CRISPR
- Promoter U6
Growth in Bacteria
Growth Strain(s)NEB Stable
- Cloning method Restriction Enzyme
- 5′ sequencing primer cgggtttattacagggacagcag
- 3′ sequencing primer taccagtcaatctttcacaaattttgt (Common Sequencing Primers)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pLX-sgRNA-BfuAI-2k was a gift from Ren-Jang Lin (Addgene plasmid # 112915 ; http://n2t.net/addgene:112915 ; RRID:Addgene_112915)
For your References section:MicroRNA-focused CRISPR-Cas9 Library Screen Reveals Fitness-Associated miRNAs. Kurata JS, Lin RJ. RNA. 2018 May 2. pii: rna.066282.118. doi: 10.1261/rna.066282.118. 10.1261/rna.066282.118 PubMed 29720387
