pBEST-HipO
(Plasmid #114599)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 114599 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBEST-OR2-OR1-Pr-UTR1-deGFP-T500
  • Modifications to backbone
    The gene deGFP was replaced by HipO.
  • Vector type
    Synthetic Biology ; Cell-Free Protein Synthesis

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    HipO
  • Species
    Campylobacter jejuni
  • Insert Size (bp)
    1152
  • Promoter OR2-OR1-Pr

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ATGCTGAGCTAACACCGTGC
  • 3′ sequencing primer GGCACCTGTCCTACGAGTTG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBEST-HipO was a gift from Jerome Bonnet (Addgene plasmid # 114599 ; http://n2t.net/addgene:114599 ; RRID:Addgene_114599)
  • For your References section:

    Plug-and-play metabolic transducers expand the chemical detection space of cell-free biosensors. Voyvodic PL, Pandi A, Koch M, Conejero I, Valjent E, Courtet P, Renard E, Faulon JL, Bonnet J. Nat Commun. 2019 Apr 12;10(1):1697. doi: 10.1038/s41467-019-09722-9. 10.1038/s41467-019-09722-9 PubMed 30979906
