YFP-CL1
(Plasmid #11950)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 11950 Standard format: Plasmid sent in bacteria as agar stab 1 $94
Add to Cart
DNA 11950-D50 50 μg of DNA in Tris buffer $495
Add to Cart
DNA 11950-D100 100 μg of DNA in Tris buffer $585
Add to Cart

Backbone

  • Vector backbone
    EGFP-C1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3932
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    YFP-CL1
  • Alt name
    Ubiquitin
  • Alt name
    Ub
  • Insert Size (bp)
    826

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer EGFP-C
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The YFP-CL1 reporter was generated by inserting an oligodimer encoding the 16 amino acid CL1 degradation signal (ACKNWFSSLSHFVIHL) in enhanced GFP-C1 (BD Biosciences Clontech) using the EcoRI and BamH1 restriction sites, then the enhanced GFP open-reading frame was replaced with YFP using the Nhe1 and SspB1 restriction sites.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 50 μg
  • Concentration 1 μg/μL
  • Pricing $495 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

Purpose

Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.

Delivery

  • Amount 100 μg
  • Concentration 1 μg/μL
  • Pricing $585 USD
  • Storage 4 ℃ (short-term) or -20 ℃ (long-term)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Quality Control

Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.

Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    YFP-CL1 was a gift from Nico Dantuma (Addgene plasmid # 11950 ; http://n2t.net/addgene:11950 ; RRID:Addgene_11950)

  • For your References section:

    Endoplasmic reticulum stress compromises the ubiquitin-proteasome system. Menendez-Benito V, Verhoef LG, Masucci MG, Dantuma NP. Hum Mol Genet. 2005 Oct 1. 14(19):2787-99. 10.1093/hmg/ddi312 PubMed 16103128
