PurposeAAV-mediated expression of tdTomato under the EF1α promoter (1.1kb short version). tdTomato has codons varied to reduce recombination. Using SV40 pA signal.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||122101||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
Backbone manufacturerScott Sternson lab
- Backbone size w/o insert (bp) 4980
- Total vector size (bp) 6411
Vector typeMammalian Expression, AAV
Growth in Bacteria
Growth Strain(s)NEB Stable
Growth instructionsCan use DH5alpha at 37°C or Stbl3 at 30°C. Carbenicillin is preferred over ampicillin. In DH5alpha this plasmid may act more like a high copy plasmid, although in Stbl3 it may act more like a low copy plasmid.
Copy numberHigh Copy
Insert Size (bp)1431
- Promoter EF1a（1.1kb short version)
/ Fusion Protein
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer ggatcttggttcattctcaag
- 3′ sequencing primer aaagagacagcaaccagg (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
The plasmid is fully sequenced in the coding sequence regions (fluorophore region). Multiple digestions were done to verify the vector structure. The construct was tested in vitro.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pAAV-EF1α1.1-tdTomato was a gift from Edward Boyden (Addgene plasmid # 122101 ; http://n2t.net/addgene:122101 ; RRID:Addgene_122101)
For your References section:Independent optical excitation of distinct neural populations. Klapoetke NC, Murata Y, Kim SS, Pulver SR, Birdsey-Benson A, Cho YK, Morimoto TK, Chuong AS, Carpenter EJ, Tian Z, Wang J, Xie Y, Yan Z, Zhang Y, Chow BY, Surek B, Melkonian M, Jayaraman V, Constantine-Paton M, Wong GK, Boyden ES. Nat Methods. 2014 Mar;11(3):338-46. doi: 10.1038/nmeth.2836. Epub 2014 Feb 9. 10.1038/nmeth.2836 PubMed 24509633
