PurposeFor orthogonal R loop assay (use with Sp-derived base editor, Sp gRNA, and Sa gRNA for assay)
-
Depositing Lab
-
Depositing OrganizationBroad Institute
Located in United States of America -
Citations
-
Sequence Information
Ordering
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 138162 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $94 | |
| DNA | 138162-D50 | 50 μg of DNA in Tris buffer | $495 | ||
| DNA | 138162-D100 | 100 μg of DNA in Tris buffer | $585 | ||
Backbone
-
Vector backbonepBR322/CMV
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namedSaCas9
-
Alt namedSauCas9
-
SpeciesS. aureus
-
MutationD10A + N580A
- Promoter CMV
-
Tags
/ Fusion Proteins
- NLS (N terminal on insert)
- NLS (C terminal on insert)
Cloning Information
- Cloning method Ligation Independent Cloning
Resource Information
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
DNA (Catalog # 138162-D50)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 50 μg
- Concentration 1 μg/μL
- Pricing $495 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
DNA (Catalog # 138162-D100)
Purpose
Ready-to-use, high-purity DNA prep. DNA aliquots are suitable for use in mammalian cell transfections and other molecular biology applications.
Delivery
- Amount 100 μg
- Concentration 1 μg/μL
- Pricing $585 USD
- Storage 4 ℃ (short-term) or -20 ℃ (long-term)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Quality Control
Every DNA prep is verified by next-generation sequencing, confirming plasmid identity, sequence integrity, and absence of DNA contaminants. Concentration is confirmed to be within ±2.5% of the stated concentration.
Our production process has been validated to consistently yield endotoxin levels below 1.0 EU/μg. Individual lots are not tested for endotoxin.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
dead Sa Cas9 was a gift from David Liu (Addgene plasmid # 138162 ; http://n2t.net/addgene:138162 ; RRID:Addgene_138162) -
For your References section:
Evaluation and minimization of Cas9-independent off-target DNA editing by cytosine base editors. Doman JL, Raguram A, Newby GA, Liu DR. Nat Biotechnol. 2020 Feb 10. pii: 10.1038/s41587-020-0414-6. doi: 10.1038/s41587-020-0414-6. 10.1038/s41587-020-0414-6 PubMed 32042165
