(Plasmid #161920)


Item Catalog # Description Quantity Price (USD)
Plasmid 161920 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Addgene #46956
  • Backbone size w/o insert (bp) 4756
  • Total vector size (bp) 7222
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    BRCA1-associated ATM activator 1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Entrez Gene
    BRAT1 (a.k.a. BAAT1, C7orf27, NEDCAS, RMFSL)
  • Promoter CMV
  • Tag / Fusion Protein
    • GFP-FLAG (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NotI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer SEQ-GFPC-F (CATGGTCCTGCTGGAGTTCGTG)
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFP-C1-FLAG-BRAT1 was a gift from Sébastien Britton (Addgene plasmid # 161920 ; ; RRID:Addgene_161920)
  • For your References section:

    SDR enzymes oxidize specific lipidic alkynylcarbinols into cytotoxic protein-reactive species. Demange P, Joly E, Marcoux J, Zanon PRA, Listunov D, Rulliere P, Barthes C, Noirot C, Izquierdo JB, Rozie A, Pradines K, Hee R, de Brito MV, Marcellin M, Serre RF, Bouchez O, Burlet-Schiltz O, Oliveira MCF, Ballereau S, Bernardes-Genisson V, Maraval V, Calsou P, Hacker SM, Genisson Y, Chauvin R, Britton S. Elife. 2022 May 10;11. pii: 73913. doi: 10.7554/eLife.73913. 10.7554/eLife.73913 PubMed 35535493
