(Plasmid #163649)


Item Catalog # Description Quantity Price (USD)
Plasmid 163649 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Dr. Lu Lei's lab
  • Backbone size w/o insert (bp) 6171
  • Total vector size (bp) 9600
  • Modifications to backbone
    The myc tag in this vector was replaced with GFP tag using SacII/NotI digestion.
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    mannosidase alpha class 2A member 1
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Mutation
    Silent mutation was made to introduce a XbaI restriction site in Man2a1
  • GenBank ID
  • Entrez Gene
    MAN2A1 (a.k.a. AMan II, GOLIM7, MANA2, MANII)
  • Tag / Fusion Protein
    • GFP (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site SacII (not destroyed)
  • 5′ sequencing primer CMV-F or T7
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Man2a1-GFP was a gift from Lei Lu (Addgene plasmid # 163649 ; ; RRID:Addgene_163649)
  • For your References section:

    A quantitative study of the Golgi retention of glycosyltransferases. Sun X, Mahajan D, Chen B, Song Z, Lu L. J Cell Sci. 2021 Oct 15;134(20). pii: 272560. doi: 10.1242/jcs.258564. Epub 2021 Oct 21. 10.1242/jcs.258564 PubMed 34533190
