pAAV Syn CaMPARI2-F391W_L398V-human-a-Tubulin (high affinity TubuTag)
(Plasmid #164193)

• Purpose: Freeze-frame imaging of dendritic calcium signals High calcium affinity (CaMPARI2_F391W_L398V moiety Kd=174nM)
• Depositing Lab: Thomas Oertner
• Publication: Perez-Alvarez et al Front Mol Neurosci. 2021 Mar 4;14:635820. doi: 10.3389/fnmol.2021.635820. eCollection 2021.

Backbone

• Vector backbone: pAAV
• Backbone manufacturer: Stratagene
• Backbone size w/o insert (bp): 4579
• Total vector size (bp): 7275
• Vector type: Mammalian Expression, AAV

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert 1

• Gene/Insert name: CamPARI2
• Species: Synthetic
• Insert Size (bp): 1306
• Mutation: F391W-L398V
• Promoter: Syn
• Tags / Fusion Proteins:
  • NES (N terminal on insert)
  • 6 His tag (N terminal on insert)

Cloning Information for Gene/Insert 1

• Cloning method: Restriction Enzyme
• 5′ cloning site: NheI (not destroyed)
• 3′ cloning site: Bsp1407I (not destroyed)
• 5′ sequencing primer: GACTCAGCGCTGCCTCAGTCTG
• 3′ sequencing primer: CTTGTACATTGAGCTCAGCCGACCTATAG

Gene/Insert 2

• Gene/Insert name: Human α Tubulin
• Alt name: h a Tubulin
• Alt name: TubuTag high affinity
• Species: H. sapiens (human)
• Insert Size (bp): 1353
• Promoter: Syn

Cloning Information for Gene/Insert 2

• Cloning method: Restriction Enzyme
• 5′ cloning site: Bgl II (not destroyed)
• 3′ cloning site: HindIII (not destroyed)
• 5′ sequencing primer: ctattttaagcagtcgtttc
• 3′ sequencing primer: GGCATTAAAGCAGCGTATCC

Resource Information

• A portion of this plasmid was derived from a plasmid made by: We kindly received CaMPARI2 fromEric Schreiter, Janelia farm USA and Human α Tubulin was a kind gift from Marina Mikhaylova's lab

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry
