Flag-M4-AR-S650D
(Plasmid #171246)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 171246 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    p3XFLAG-CMV-10
  • Backbone manufacturer
    Sigma-Aldrich
  • Backbone size w/o insert (bp) 6400
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    3xFlag-tagged human androgen receptor Ser650Asp mutant
  • Alt name
    Flag-AR-S650D
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    3000
  • Mutation
    AR-Ser650Asp (AR-S650D)
  • Entrez Gene
    AR (a.k.a. AIS, AR8, DHTR, HUMARA, HYSP1, KD, NR3C4, SBMA, SMAX1, TFM)
  • Promoter CMV
  • Tag / Fusion Protein
    • Flag (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (unknown if destroyed)
  • 3′ cloning site NotI (unknown if destroyed)
  • 5′ sequencing primer CMV_fwd_primer
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Mutation in Flag-tagged AR Ser-Pro phosphorylation site, and the exact amino acid residue position and composition may slightly vary based on human AR versions. Two XmaI sites on the vector backbone and one EcoRI site at the 3'UTR of AR cDNA were deleted by DNA mutagenesis.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Flag-M4-AR-S650D was a gift from Steven Balk (Addgene plasmid # 171246 ; http://n2t.net/addgene:171246 ; RRID:Addgene_171246)
  • For your References section:

    Protein phosphatase 1 suppresses androgen receptor ubiquitylation and degradation. Liu X, Han W, Gulla S, Simon NI, Gao Y, Cai C, Yang H, Zhang X, Liu J, Balk SP, Chen S. Oncotarget. 2016 Jan 12;7(2):1754-64. doi: 10.18632/oncotarget.6434. 10.18632/oncotarget.6434 PubMed 26636645
