pJK2014
(Plasmid
#171931)
-
PurposeTo express sygl-1 fused to 24 copies of MS2 loops.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 171931 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $89 | |
Backbone
-
Vector backbonepCFJ151
- Total vector size (bp) 6161
-
Vector typeWorm Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namePsygl-1::24XMS2 loops::3X Flag::sygl-1 ORF::sygl-1 3'UTR
-
SpeciesC. elegans (nematode)
-
Insert Size (bp)6161
-
GenBank ID31378588
- Promoter -
-
Tag
/ Fusion Protein
- N-terminal Tag 24X MS2 loops
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer -
- 3′ sequencing primer - (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJK2014 was a gift from Judith Kimble (Addgene plasmid # 171931 ; http://n2t.net/addgene:171931 ; RRID:Addgene_171931) -
For your References section:
Dynamics of Notch-Dependent Transcriptional Bursting in Its Native Context. Lee C, Shin H, Kimble J. Dev Cell. 2019 Aug 19;50(4):426-435.e4. doi: 10.1016/j.devcel.2019.07.001. Epub 2019 Aug 1. 10.1016/j.devcel.2019.07.001 PubMed 31378588
