|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||17605||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 4800
Vector typeMammalian Expression
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Copy numberHigh Copy
Gene/Insert nameUbiquitin C
SpeciesH. sapiens (human)
Insert Size (bp)220
MutationK48 only, other lysines mutated to arginines. Enhances the G76-K48-linked polyubiquitination of proteins.
Entrez GeneUBC (a.k.a. HMG20)
/ Fusion Protein
- HA (N terminal on backbone)
- Cloning method Restriction Enzyme
- 5′ cloning site SalI (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer SP6 (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pRK5-HA-Ubiquitin-K48 was a gift from Ted Dawson (Addgene plasmid # 17605 ; http://n2t.net/addgene:17605 ; RRID:Addgene_17605)
For your References section:Parkin mediates nonclassical, proteasomal-independent ubiquitination of synphilin-1: implications for Lewy body formation. Lim KL, Chew KC, Tan JM, Wang C, Chung KK, Zhang Y, Tanaka Y, Smith W, Engelender S, Ross CA, Dawson VL, Dawson TM. J Neurosci. 2005 Feb 23. 25(8):2002-9. 10.1523/JNEUROSCI.4474-04.2005 PubMed 15728840
