pTRIP CMV VHHG4
(Plasmid #182236)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 182236 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pTRIP CMV
  • Backbone size w/o insert (bp) 9844
  • Total vector size (bp) 10186
  • Modifications to backbone
    none
  • Vector type
    Mammalian Expression, Lentiviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    anti-GFP nanobody
  • Alt name
    GFP-binding fragment of a single-chain camelid antibody
  • Insert Size (bp)
    342
  • Promoter CMV
  • Tags / Fusion Proteins
    • Myc (C terminal on insert)
    • His (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer gtggctaagatctacagctg
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTRIP CMV VHHG4 was a gift from Stéphanie Cabantous (Addgene plasmid # 182236 ; http://n2t.net/addgene:182236 ; RRID:Addgene_182236)
  • For your References section:

    High-content tripartite split-GFP cell-based assays to screen for modulators of small GTPase activation. Koraichi F, Gence R, Bouchenot C, Grosjean S, Lajoie-Mazenc I, Favre G, Cabantous S. J Cell Sci. 2018 Jan 8;131(1). pii: jcs.210419. doi: 10.1242/jcs.210419. 10.1242/jcs.210419 PubMed 29192060
