|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||20942||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 9000
Vector typeMammalian Expression, Lentiviral
Growth in Bacteria
Copy numberHigh Copy
Insert Size (bp)1662
MutationH134R mutation in ChR2
- Cloning method Restriction Enzyme
- 5′ cloning site AgeI (unknown if destroyed)
- 3′ cloning site EcoRI (unknown if destroyed)
- 5′ sequencing primer n/a (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
Articles Citing this Plasmid
Please see http://www.optogenetics.org
for additional information.
The H134R mutation present in ChR2 sequence is a gain-of-function mutant that produces larger stationary photocurrents in comparison to the wild-type ChR2 sequence
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pLenti-EF1a-hChR2(H134R)-EYFP-WPRE was a gift from Karl Deisseroth (Addgene plasmid # 20942 ; http://n2t.net/addgene:20942 ; RRID:Addgene_20942)
For your References section:Multimodal fast optical interrogation of neural circuitry. Zhang F, Wang LP, Brauner M, Liewald JF, Kay K, Watzke N, Wood PG, Bamberg E, Nagel G, Gottschalk A, Deisseroth K. Nature. 2007 Apr 5. 446(7136):633-9. 10.1038/nature05744 PubMed 17410168
