pHis-TEV-Nsp15-A81V
(Plasmid
#219525)
-
PurposeE. coli plasmid (T7lac promoter) for full-length, SARS CoV-2 Nsp15-A81V (uridine-specific nidoviral endoribonuclease, expression-optimized gene) with N-terminal TEV protease cleavable His6-tag
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 219525 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET-11b
-
Backbone manufacturerpurchased from GenScript
- Backbone size w/o insert (bp) 5644
- Total vector size (bp) 6760
-
Modifications to backboneNone. GenScript cloned the expression-optimized insert into NdeI and BamHI sites of pET-11b.
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert nameNsp15-A81V
-
Alt nameNendoU-A81V
-
Alt namenon-structural protein 15, A81V
-
Alt nameuridylate-specific endoribonuclease, A81V
-
SpeciesSevere acute respiratory syndrome coronavirus 2
-
Insert Size (bp)1037
-
MutationA81V (C to T)
-
Entrez GeneN (a.k.a. GU280_gp10)
-
Tag
/ Fusion Protein
- TEV protease cleavable His6-tag (N terminal on insert)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byPurchased from GenScript the expression-optimized insert in the pET-11b backbone
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Protein sequence is MHHHHHHSSGVDLGTENLYFQSNAM + Nsp15-A81V (amino acid residues 6453-6798 of YP_009724389, with A81V mutation).
Confers ampicillin-resistance.
Backbone vector is pET-11b from GenScript.
Mutation design by Nirupa Nagaratnam.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pHis-TEV-Nsp15-A81V was a gift from Debra Hansen (Addgene plasmid # 219525 ; http://n2t.net/addgene:219525 ; RRID:Addgene_219525) -
For your References section:
Functional implications of hexameric dynamics in SARS-CoV-2 Nsp15. Sonowal M, Ketawala G, Nagaratnam N, Logeswaran D, Basu S, de Sanctis D, Orlans J, Rose SL, Jernigan RJ, Hu H, Aguilar JDM, Ranaweera ME, Zacks MA, Chen JJ, Hansen DT, Schrag LG, Fromme R, Botha S, Fromme P. Protein Sci. 2025 Jun;34(6):e70115. doi: 10.1002/pro.70115. 10.1002/pro.70115 PubMed 40411374
