RUBY-ABE#2
(Plasmid
#232176)
-
PurposeT-DNA vector with ecTadA8e-zCas9D10A and corresponding sgRNA to correct RUBYm2 and recover a vivid red color visible to the naked eyes.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 232176 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $89 |
Backbone
-
Vector backbonepYPQ166-ABE8e
-
Vector typePlant Expression, CRISPR
-
Selectable markersKanamycin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert name2x35s-ecTadA8e-SpCas9-D10A-AtU3-sgRNA-mis4-gRNA scaffold
-
Tags
/ Fusion Proteins
- NLS
- 3xflag
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
The Addgene NGS result differs slightly from the depositor's provided sequence: 2bp and a 1bp indel in 2x35S promoter. The depositor notes that this is not of concern for the plasmid's function.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
RUBY-ABE#2 was a gift from Yiping Qi (Addgene plasmid # 232176 ; http://n2t.net/addgene:232176 ; RRID:Addgene_232176) -
For your References section:
Seeing is believing: Genome editing made easy with RUBY for educational purposes. Sexton WK, Cheng Y, Yang B, Ullah H, Qi Y, Xiao S. Plant Physiol. 2025 Jul 3;198(3):kiaf265. doi: 10.1093/plphys/kiaf265. 10.1093/plphys/kiaf265 PubMed 40696509
