pSJX016
(Plasmid #232324)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 232324 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBXMCS2
  • Vector type
    Bacterial Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert 1

  • Gene/Insert name
    sgRNA
  • Alt name
    spmX
  • Alt name
    Lysozyme-family localization factor spmX
  • Species
    Caulobacter crescentus
  • Promoter PJ23119
  • Tag / Fusion Protein
    • H-arms (C terminal on insert)

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    SpCas9M
  • Promoter Pvan
  • Tag / Fusion Protein
    • sfGFP (C terminal on insert)

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

sgRNA sequence: tctcttgatgagatcgacgg

Please visit https://doi.org/10.1101/2024.12.02.626314 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSJX016 was a gift from Wei Zhao (Addgene plasmid # 232324 ; http://n2t.net/addgene:232324 ; RRID:Addgene_232324)

  • For your References section:

    A CRISPR/SpCas9M-reporting system for efficient and rapid genome editing in Caulobacter crescentus. Sun J, Yu X, Tang G, Chen M, Zheng Y, Hu Y, Li Q, Li X, Li N, Li Z, Li Y, Lu N, Tan W, Yang Y, Zeng X, Zhao G, Wang H, Dai L, Zhao G, Ai L, Zhao W. bioRxiv 2024.12.02.626314 10.1101/2024.12.02.626314
