pAAV-CaMKII-Ace-mNeon1-WPRE
(Plasmid #240053)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 240053 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    AAV
  • Vector type
    AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Ace-mNeon1
  • Alt name
    Ace2N-4AA-mNeon
  • Species
    Synthetic
  • Promoter CaMKII

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Gong Y, Huang C, Li JZ, Grewe BF, Zhang Y, Eismann S, Schnitzer MJ. (2015) High-speed recording of neural spikes in awake mice and flies with a fluorescent voltage sensor. Science. 350(6266):1361-1366.

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-CaMKII-Ace-mNeon1-WPRE was a gift from Mark Schnitzer (Addgene plasmid # 240053 ; http://n2t.net/addgene:240053 ; RRID:Addgene_240053)

  • For your References section:

    Imaging high-frequency voltage dynamics in multiple neuron classes of behaving mammals. Haziza S, Chrapkiewicz R, Zhang Y, Kruzhilin V, Li J, Li J, Delamare G, Swanson R, Buzsaki G, Kannan M, Vasan G, Lin MZ, Zeng H, Daigle TL, Schnitzer MJ. Cell, 188, 1-23, August 7, 2025. doi: 10.1016/j.cell.2025.06.028 10.1016/j.cell.2025.06.028 PubMed 39185175
