TPC2-GCaMP6s
(Plasmid #240465)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 240465 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pDendra2-N
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3964
  • Total vector size (bp) 7612
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TPC2N2
  • Alt name
    TPC2, two-pore channel 2
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2256
  • GenBank ID
    BC141195
  • Entrez Gene
    TPCN2 (a.k.a. SHEP10, TPC2)
  • Promoter CMV
  • Tag / Fusion Protein
    • GCaMP6s (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CAA CGG GAC TTT CCA AAA TG
  • 3′ sequencing primer GAAATTTGTGATGCTATTGC
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    TPC2-GCaMP6s was a gift from Antony Galione (Addgene plasmid # 240465 ; http://n2t.net/addgene:240465 ; RRID:Addgene_240465)

  • For your References section:

    Optical profiling of autonomous Ca(2+) nanodomains generated by lysosomal TPC2 and TRPML1. Davis LC, Morgan AJ, Galione A. Cell Calcium. 2023 Dec;116:102801. doi: 10.1016/j.ceca.2023.102801. Epub 2023 Sep 18. 10.1016/j.ceca.2023.102801 PubMed 37742482
