pMAL-pHluorin4
(Plasmid #241868)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 241868 Standard format: Plasmid sent in bacteria as agar stab 1 $89
Add to Cart

Backbone

  • Vector backbone
    pMAL
  • Backbone manufacturer
    New England Biolabs
  • Backbone size w/o insert (bp) 6200
  • Total vector size (bp) 6378
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    MBP-pHluorin4
  • Insert Size (bp)
    1881

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Sequence was synthesized based on the sequences of pHluorin2 (doi 10.4236/abb.2011.23021) and sfGFP (doi: 10.1038/nbt0906-1170d)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry

Trademarks:

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMAL-pHluorin4 was a gift from Ian Thornell (Addgene plasmid # 241868 ; http://n2t.net/addgene:241868 ; RRID:Addgene_241868)

  • For your References section:

    The pH-dependent photophysical and spectral properties of pH-sensing green fluorescent proteins. Thornell IM. Physiol Rep. 2025 Oct;13(20):e70625. doi: 10.14814/phy2.70625. 10.14814/phy2.70625 PubMed 41108577
