Purpose3rd gen lentiviral expression of eNpHR 3.0 fused to EYFP driven by CaMKIIa promoter for optogenetic inhibition
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||26970||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 9253
Vector typeMammalian Expression, Lentiviral
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Growth instructionsStbl3 (rec A-) cells to avoid recombinations with the LTRs
Copy numberHigh Copy
Gene/Insert nameeNpHR 3.0
SpeciesH. sapiens (human)
Insert Size (bp)1683
MutationTrafficking Signal (TS), ER Export Signal (FCYENE)
/ Fusion Protein
- EYFP (C terminal on insert)
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI, AgeI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer ctcagaagccccaagctcgtc
- 3′ sequencing primer GCAATAGCATGATACAAAGG (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
This plasmid contains the mouse calcium/calmodulin-dependent kinase II alpha subunit promoter.
For additional information please visit - http://www.optogenetics.org
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pLenti-CaMKIIa-eNpHR 3.0-EYFP was a gift from Karl Deisseroth (Addgene plasmid # 26970 ; http://n2t.net/addgene:26970 ; RRID:Addgene_26970)
