pSUPER-CXCR4
(Plasmid #42052)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 42052 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pSuper.Retro.Puro
  • Backbone manufacturer
    OligoEngine
  • Backbone size w/o insert (bp) 6348
  • Total vector size (bp) 6410
  • Vector type
    Mammalian Expression, Retroviral, RNAi
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CXCR4 shRNA
  • gRNA/shRNA sequence
    UGUUAGCUGGAGUGAAAACUU
  • Entrez Gene
    CXCR4 (a.k.a. CD184, D2S201E, FB22, HM89, HSY3RR, LAP-3, LAP3, LCR1, LESTR, NPY3R, NPYR, NPYRL, NPYY3R, WHIM, WHIMS)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (destroyed during cloning)
  • 3′ cloning site HindIII (destroyed during cloning)
  • 5′ sequencing primer TCGCTATGTGTTCTGGGAAA
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSUPER-CXCR4 was a gift from Kumiko Ui-Tei (Addgene plasmid # 42052 ; http://n2t.net/addgene:42052 ; RRID:Addgene_42052)
  • For your References section:

    Human TNRC6A is an Argonaute-navigator protein for microRNA-mediated gene silencing in the nucleus. Nishi K, Nishi A, Nagasawa T, Ui-Tei K. RNA. 2013 Jan;19(1):17-35. doi: 10.1261/rna.034769.112. Epub 2012 Nov 13. 10.1261/rna.034769.112 PubMed 23150874
