pTK88_GFP-Anillin
(Plasmid #46354)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 46354 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pBABE
  • Backbone size w/o insert (bp) 6000
  • Total vector size (bp) 9259
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers
    Blasticidin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Anillin
  • Species
    H. sapiens (human)
  • Mutation
    a1854 is changed to c to disrupt XhoI site without affecting coding amino acid sequence
  • Entrez Gene
    ANLN (a.k.a. FSGS8, Scraps, scra)
  • Promoter pBABE
  • Tag / Fusion Protein
    • GFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site SacII (not destroyed)
  • 5′ sequencing primer GGCATGGACGAGCTGTACAAG
  • 3′ sequencing primer GCATTCATTTTATGTTTCAGG
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTK88_GFP-Anillin was a gift from Iain Cheeseman (Addgene plasmid # 46354 ; http://n2t.net/addgene:46354 ; RRID:Addgene_46354)
