(Plasmid #48700)


Item Catalog # Description Quantity Price (USD)
Plasmid 48700 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 5790
  • Total vector size (bp) 7977
  • Modifications to backbone
    EGFP added at 5' end of open reading frame for fusion to snf-5.
  • Vector type
    Mammalian Expression ; Xenopus Oocyte Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    Room Temperature
  • Growth Strain(s)
  • Copy number
    Low Copy


  • Gene/Insert name
  • Alt name
  • Species
    C. elegans (nematode)
  • Insert Size (bp)
  • Entrez Gene
    snf-5 (a.k.a. CELE_Y46G5A.30)
  • Promoter T7
  • Tag / Fusion Protein
    • EGFP (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer ATG GCC GAT TCG GGC AGC AAT GA
  • 3′ sequencing primer T TAA TAA ACT TGA TGA TAT GTA
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    The original plasmid (pXOON) was donated by the laboratory of Thomas Jespersen at the University of Copanhagen, Denmark.

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    5' EGFP SNF-5 pXOON was a gift from Dmitri Boudko (Addgene plasmid # 48700 ; ; RRID:Addgene_48700)
