(Plasmid #49086)


Item Catalog # Description Quantity Price (USD)
Plasmid 49086 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 6290
  • Total vector size (bp) 7590
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Tetracycline, 10 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    Low Copy

Gene/Insert 1

  • Gene/Insert name
    tRNA synthetase
  • Species
    M. barkeri
  • Mutation
    L274M, C313A, Y349F
  • Promoter lpp

Cloning Information for Gene/Insert 1

Gene/Insert 2

  • Gene/Insert name
    tRNA for a photocrosslinking amino acid
  • Species
  • Promoter GlnRS

Cloning Information for Gene/Insert 2

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pDULE-ABK was a gift from Peter Schultz (Addgene plasmid # 49086 ; ; RRID:Addgene_49086)
  • For your References section:

    Probing protein-protein interactions with a genetically encoded photo-crosslinking amino acid. Ai HW, Shen W, Sagi A, Chen PR, Schultz PG. Chembiochem. 2011 Aug 16;12(12):1854-7. doi: 10.1002/cbic.201100194. Epub 2011 Jun 15. 10.1002/cbic.201100194 PubMed 21678540
