PurposeDouble floxed Gi-coupled hM4D DREADD fused with mCherry under the control of EF1a promoter
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 50461 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepAAV
- Backbone size w/o insert (bp) 4818
- Total vector size (bp) 7772
-
Vector typeAAV
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Stbl3
-
Copy numberLow Copy
Gene/Insert
-
Gene/Insert namehM4D(Gi)-mCherry
-
SpeciesH. sapiens (human)
-
Insert Size (bp)2175
-
MutationSee supplemental documents for DREADD mutations
-
Entrez GeneCHRM4 (a.k.a. HM4, M4R)
- Promoter EF1a
-
Tags
/ Fusion Proteins
- HA (N terminal on insert)
- mCherry (C terminal on insert)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site Asc I (not destroyed)
- 3′ cloning site Nhe I (not destroyed)
- 5′ sequencing primer TTTTTGAGTTTGGATCTTGG
- 3′ sequencing primer GCATTAAAGCAGCGTATCCACATAGC (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Addgene Notes
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
These plasmids were generated as part of the Illuminating the Druggable Genome (IDG) program sponsored by the NIH Common Fund. The goal of this program is to identify, gather, and distribute information and resources for proteins that currently are not well-studied yet belong to commonly drug-targeted protein families: protein kinases, non-olfactory G-protein coupled receptors (GPCRs), and ion channels. The IDG program is designed to develop fundamental research tools for understudied proteins, elucidate their function, and disseminate the IDG-related resources and data to the greater scientific community.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pAAV-EF1a-DIO-hM4D(Gi)-mCherry was a gift from Bryan Roth (Addgene plasmid # 50461 ; http://n2t.net/addgene:50461 ; RRID:Addgene_50461)
