(Plasmid #52326)


Item Catalog # Description Quantity Price (USD)
Plasmid 52326 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    NRC Biotechnology Research Institute
  • Backbone size w/o insert (bp) 4401
  • Total vector size (bp) 5300
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Mutation
    R117Q mutation (R95Q according to numbering in Fig. 2A of associated publication)
  • Entrez Gene
    SDC1 (a.k.a. CD138, SDC, SYND1, syndecan)
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Hind III (not destroyed)
  • 3′ cloning site BamHI (not destroyed)
  • 5′ sequencing primer CCATACACTTGAGTGACAATGAC
  • 3′ sequencing primer TATGTCCTTCCGAGTGAGAG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    pTT5 backbone used in his plasmids was obtained from Yves Durocher at National Research Council of Canada (NRC)
  • Articles Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTT5-hSDC1 was a gift from Gordon Laurie (Addgene plasmid # 52326 ; ; RRID:Addgene_52326)
  • For your References section:

    Targeting of heparanase-modified syndecan-1 by prosecretory mitogen lacritin requires conserved core GAGAL plus heparan and chondroitin sulfate as a novel hybrid binding site that enhances selectivity. Zhang Y, Wang N, Raab RW, McKown RL, Irwin JA, Kwon I, van Kuppevelt TH, Laurie GW. J Biol Chem. 2013 Apr 26;288(17):12090-101. doi: 10.1074/jbc.M112.422717. Epub 2013 Mar 15. 10.1074/jbc.M112.422717 PubMed 23504321
