(Plasmid #58376)


This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 58376 Standard format: Plasmid sent in bacteria as agar stab 1 $85


  • Vector backbone
  • Backbone manufacturer
    Applied Viromics, Fremont, CA, USA
  • Total vector size (bp) 6519
  • Modifications to backbone
    mU6.siRNA cassette removed
  • Vector type
    Mammalian Expression, AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
    proprotein convertase subtilisin/kexin type 9
  • Alt name
  • Alt name
  • Species
    M. musculus (mouse)
  • Insert Size (bp)
  • Mutation
  • Entrez Gene
    Pcsk9 (a.k.a. AI415265, AI747682, FH3, HCHOLA3, Narc1, PC9)
  • Promoter HCRApoE/hAAT

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site FseI (not destroyed)
  • 5′ sequencing primer na
  • 3′ sequencing primer na
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV/D377Y-mPCSK9 was a gift from Jacob Bentzon (Addgene plasmid # 58376 ; ; RRID:Addgene_58376)
  • For your References section:

    Induction of atherosclerosis in mice and hamsters without germline genetic engineering. Bjorklund MM, Hollensen AK, Hagensen MK, Dagnaes-Hansen F, Christoffersen C, Mikkelsen JG, Bentzon JF. Circ Res. 2014 May 23;114(11):1684-9. doi: 10.1161/CIRCRESAHA.114.302937. Epub 2014 Mar 27. 10.1161/CIRCRESAHA.114.302937 PubMed 24677271
