(Plasmid #65436)


Item Catalog # Description Quantity Price (USD)
Plasmid 65436 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 6264
  • Vector type
    Mammalian Expression, Retroviral
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Insert Size (bp)
  • GenBank ID
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer LNCX-3
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Initially cloned into pBluescript: IRES-GFP digested from pIRES2-EGFP Addgene plasmid 3178 from clontech using BamHI-NotI. IRES-GFP cloned from pBluescript into pLPCX using XhoI and NotI.
  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
  • Article Citing this Plasmid
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLPCX-IRES-GFP was a gift from Trond Aasen (Addgene plasmid # 65436 ; ; RRID:Addgene_65436)
  • For your References section:

    Internal translation of the connexin 43 transcript. Salat-Canela C, Sese M, Peula C, Ramon y Cajal S, Aasen T. Cell Commun Signal. 2014 May 8;12:31. doi: 10.1186/1478-811X-12-31. 10.1186/1478-811X-12-31 PubMed 24884945
