(Plasmid #74206)


Item Catalog # Description Quantity Price (USD)
Plasmid 74206 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
    pLenti PGK GFP Blast (w510-5)
  • Backbone manufacturer
    Addgene plasmid #19069
  • Backbone size w/o insert (bp) 7563
  • Total vector size (bp) 9950
  • Modifications to backbone
    Insert was digested with BglII/PspXI and ligated into vector digested with BamHI/SalI.
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
  • Insert Size (bp)
  • Tag / Fusion Protein
    • mTurqoise (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (destroyed during cloning)
  • 3′ cloning site SalI (destroyed during cloning)
  • 5′ sequencing primer PGKforw
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    mTurqoise-Paxillin was cloned from mTurquoise-Paxillin-22 from Michael Davidson (Addgene plasmid # 55573). The backbone: pLenti PGK GFP Blast (w510-5) was a gift from Eric Campeau (Addgene plasmid # 19069).
  • Article Citing this Plasmid

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLentiblast-Paxillin-mTurqoise was a gift from Jayanta Debnath (Addgene plasmid # 74206 ; ; RRID:Addgene_74206)
  • For your References section:

    NBR1 enables autophagy-dependent focal adhesion turnover. Kenific CM, Stehbens SJ, Goldsmith J, Leidal AM, Faure N, Ye J, Wittmann T, Debnath J. J Cell Biol. 2016 Feb 29;212(5):577-590. Epub 2016 Feb 22. 10.1083/jcb.201503075 PubMed 26903539
