PurposePlasmid for incorporating the non-canonical amino acid IBBN with the Mj IBBN (G2) synthetase and cognate amber suppressing tRNA in Ecoli.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||85501||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 5400
- Total vector size (bp) 6300
Vector typeBacterial Expression
Growth in Bacteria
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
Copy numberLow Copy
Gene/Insert nameIBBN (G2) synthetase and cognate amber suppressing tRNA derived from M. jannaschii Tyrosine synthetase/tRNA system
Alt nameIBBA (G2) synthetase
Alt nameBibaf (G2) synthetase
Insert Size (bp)921
MutationY32G L65E F108W Q109M D158S R162K
- Promoter lpp (constitutive)
- Cloning method Restriction Enzyme
- 5′ cloning site NcoI (not destroyed)
- 3′ cloning site KpnI (not destroyed)
- 5′ sequencing primer CGTCACTGCGTCTTTTACTG (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
This synthetase is permissive and can incorporate a variety of amino acids structurally analogous to IBBN. For a more complete functional and structural analysis of this synthetase, also see Cooley et al. Chembiochem. 2014, 15(12): 1810–1819.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pDule2-IBBN (G2) was a gift from Ryan Mehl (Addgene plasmid # 85501 ; http://n2t.net/addgene:85501 ; RRID:Addgene_85501)
For your References section:Genetically encoded initiator for polymer growth from proteins. Peeler JC, Woodman BF, Averick S, Miyake-Stoner SJ, Stokes AL, Hess KR, Matyjaszewski K, Mehl RA. J Am Chem Soc. 2010 Oct 6;132(39):13575-7. doi: 10.1021/ja104493d. 10.1021/ja104493d PubMed 20839808
