PurposeComplementary plasmid for aaRS PACE; amber codons in T7 RNAP
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||99218||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
Backbone manufacturerDavid Liu Lab
- Backbone size w/o insert (bp) 2729
- Total vector size (bp) 5620
Vector typeBacterial Expression
Growth in Bacteria
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
Copy numberHigh Copy
Gene/Insert namePpsp [SD4] T7RNAP(S12*,S203*)
Insert Size (bp)2891
Mutationamber codons at positions 12 and 203 of T7 RNA polymerase
- Promoter Ppsp
- Cloning method Ligation Independent Cloning
- 5′ sequencing primer n/a
- 3′ sequencing primer n/a (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pDB023f1 was a gift from David Liu (Addgene plasmid # 99218 ; http://n2t.net/addgene:99218 ; RRID:Addgene_99218)
For your References section:Continuous directed evolution of aminoacyl-tRNA synthetases. Bryson DI, Fan C, Guo LT, Miller C, Soll D, Liu DR. Nat Chem Biol. 2017 Oct 16. doi: 10.1038/nchembio.2474. 10.1038/nchembio.2474 PubMed 29035361
