|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||23692||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 5005
Vector typeGateway Donor vector
Growth in Bacteria
Copy numberHigh Copy
Alt namepim-1 oncogene
SpeciesH. sapiens (human)
Insert Size (bp)942
Entrez GenePIM1 (a.k.a. PIM)
- Cloning method Gateway Cloning
- 5′ sequencing primer M13pUC-fwd
- 3′ sequencing primer M13rev (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
The ORF has no Stop codon. This design enables easy recombination into a destination vector to add an epitope tag of choice and Stop codon to the ORF. Do NOT use this plasmid directly for transfections.
A set of 4 custom lentiviral vectors is available ( pLX301 (http://www.addgene.org/25895/) , pLX302 (http://www.addgene.org/25896/) , pLX303 (http://www.addgene.org/25897/) , pLX304 (http://www.addgene.org/25890/) ) to be used to express these ORFs in mammalian cells. These plasmids are not included in the kit and must be ordered separately.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:pDONR223-PIM1 was a gift from William Hahn & David Root (Addgene plasmid # 23692 ; http://n2t.net/addgene:23692 ; RRID:Addgene_23692)
For your References section:COT drives resistance to RAF inhibition through MAP kinase pathway reactivation. Johannessen CM, Boehm JS, Kim SY, Thomas SR, Wardwell L, Johnson LA, Emery CM, Stransky N, Cogdill AP, Barretina J, Caponigro G, Hieronymus H, Murray RR, Salehi-Ashtiani K, Hill DE, Vidal M, Zhao JJ, Yang X, Alkan O, Kim S, Harris JL, Wilson CJ, Myer VE, Finan PM, Root DE, Roberts TM, Golub T, Flaherty KT, Dummer R, Weber BL, Sellers WR, Schlegel R, Wargo JA, Hahn WC, Garraway LA. Nature. 2010 Nov 24. ():. 10.1038/nature09627 PubMed 21107320
