pAAV-CAG-DIO-EYFP
(Plasmid #104052)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 104052 Standard format: Plasmid sent in bacteria as agar stab 1 $85
AAV PHP.V1 104052-AAVPHP.V1 Virus (100 µL at titer ≥ 7×10¹² vg/mL) and Plasmid. $405

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pAAV
  • Backbone size w/o insert (bp) 5456
  • Vector type
    AAV

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    EYFP
  • Insert Size (bp)
    720
  • Promoter CAG

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AscI (not destroyed)
  • 3′ cloning site NheI (not destroyed)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://www.biorxiv.org/content/early/2018/01/19/246405 for bioRxiv preprint.

Information for AAV PHP.V1 (Catalog # 104052-AAVPHP.V1) ( Back to top )

Purpose

Ready-to-use AAV PHP.V1 particles produced from pAAV-CAG-DIO-EYFP (#104052). In addition to the viral particles, you will also receive purified pAAV-CAG-DIO-EYFP plasmid DNA.

CAG-driven, Cre-dependent expression of EYFP. These AAV were produced with the PHP.V1 serotype, which permits efficient transduction of brain vascular cells. These AAV preparations are suitable purity for injection into animals.

Delivery

  • Volume 100 µL
  • Titer ≥ 7×10¹² vg/mL
  • Pricing $375 USD for preparation of 100 µL virus + $30 USD for plasmid.
  • Storage Store at -80℃. Thaw just before use and keep on ice.
  • Shipment Viral particles are shipped frozen on dry ice. Plasmid DNA (≥ 200ng) will also be included in the shipment.

Viral Production & Use

  • Packaging Plasmids encode adenoviral helper sequences and AAV rep gene, PHP.V1 cap gene
    pUCmini-iCAP-PHP.V1 (plasmid #127847)
  • Buffer PBS + 0.001% Pluronic F-68 + 200 mM NaCl
  • Serotype PHP.V1
  • Purification Iodixanol gradient ultracentrifugation
  • Reporter Gene EYFP (Cre-dependent)

Biosafety

Requestor is responsible for compliance with their institution's biosafety regulations. Lentivirus is generally considered BSL-2. AAV is generally considered BSL-1, but may require BSL-2 handling depending on the insert. Biosafety Guide

Terms and Licenses

Viral Quality Control

Quality Control:
  • Addgene ensures high quality viral vectors by optimizing and standardizing production protocols and performing rigorous quality control (QC) (see a list of our QC assays). The specific QC assays performed varies for each viral lot. To learn which specific QC assays were performed on your lot, please contact us.
  • Titer: the exact titer of your sample will be reported on the tube. The titer you see listed on this page is the guaranteed minimum titer. See how titers are measured.

Please note that this vector may have a higher level of recombination than our other FLEX vectors. We are making it available because it is still useful to some scientists, but understand that you may see expression in the absence of Cre.

Visit our viral production page for more information.

Addgene Comments

Using FLEX vectors in vivo: LoxP sites in FLEX plasmids are known to recombine during DNA amplification and viral vector production, which may result in a minority of Cre-activated (i.e., "flipped") viral vectors. Addgene has measured this occurs in 0.1-0.8% of viral particles in our typical production protocol. This can lead to a small number of cells exhibiting Cre-independent transgene expression in vivo. To address this, it is necessary to optimize the injection volume and viral titer to find the optimal AAV dosage required for Cre-dependent transgene expression and function in vivo. This may include reducing the viral particle dosage in order to reduce the likelihood of Cre-independent expression.

Citation Information: When using the PHP.V1 serotype in future publications, please acknowledge Viviana Gradinaru and cite Kumar et al., Nat Methods 17(5):541-550. Pubmed.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-CAG-DIO-EYFP was a gift from Viviana Gradinaru (Addgene plasmid # 104052 ; http://n2t.net/addgene:104052 ; RRID:Addgene_104052)

    For viral preps, please replace (Addgene plasmid # 104052) in the above sentence with: (Addgene viral prep # 104052-AAVPHP.V1)

  • For your References section:

    Systemic AAV vectors for widespread and targeted gene delivery in rodents. Challis RC, Ravindra Kumar S, Chan KY, Challis C, Beadle K, Jang MJ, Kim HM, Rajendran PS, Tompkins JD, Shivkumar K, Deverman BE, Gradinaru V. Nat Protoc. 2019 Feb;14(2):379-414. doi: 10.1038/s41596-018-0097-3. 10.1038/s41596-018-0097-3 PubMed 30626963
