(Plasmid #104589)


Item Catalog # Description Quantity Price (USD)
Plasmid 104589 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 2905
  • Total vector size (bp) 5836
  • Vector type
    Mouse Targeting, AAV, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    calcium/calmodulin-dependent protein kinase II alpha
  • Alt name
  • gRNA/shRNA sequence
  • Species
    M. musculus (mouse)
  • Entrez Gene
    Camk2a (a.k.a. CaMKII, mKIAA0968)
  • Promoter None

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer ACTATCATATGCTTACCGTAAC
  • 3′ sequencing primer CGTCGCCGTCCAGCTCGACCA
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-HDR-mEGFP-camk2a was a gift from Ryohei Yasuda (Addgene plasmid # 104589 ; ; RRID:Addgene_104589)
  • For your References section:

    Virus-Mediated Genome Editing via Homology-Directed Repair in Mitotic and Postmitotic Cells in Mammalian Brain. Nishiyama J, Mikuni T, Yasuda R. Neuron. 2017 Oct 18. pii: S0896-6273(17)30933-9. doi: 10.1016/j.neuron.2017.10.004. 10.1016/j.neuron.2017.10.004 PubMed 29056297
