(Plasmid #110193)


Item Catalog # Description Quantity Price (USD)
Plasmid 110193 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Species
    H. sapiens (human)
  • Entrez Gene
    CCR5 (a.k.a. CC-CKR-5, CCCKR5, CCR-5, CD195, CKR-5, CKR5, CMKBR5, IDDM22)
  • Promoter CMV
  • Tag / Fusion Protein
    • mTFP1 (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site unknown (unknown if destroyed)
  • 3′ cloning site unknown (unknown if destroyed)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    hCCR5-mTFP1 was a gift from Sergi Padilla Parra (Addgene plasmid # 110193 ; ; RRID:Addgene_110193)
  • For your References section:

    A dynamic three-step mechanism drives the HIV-1 pre-fusion reaction. Iliopoulou M, Nolan R, Alvarez L, Watanabe Y, Coomer CA, Jakobsdottir GM, Bowden TA, Padilla-Parra S. Nat Struct Mol Biol. 2018 Sep;25(9):814-822. doi: 10.1038/s41594-018-0113-x. Epub 2018 Aug 27. 10.1038/s41594-018-0113-x PubMed 30150645
