(Plasmid #166970)


Item Catalog # Description Quantity Price (USD)
Plasmid 166970 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
    Vector Builder
  • Backbone size w/o insert (bp) 4500
  • Total vector size (bp) 6500
  • Vector type
    Mammalian Expression, AAV, Cre/Lox

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    Homo sapiens opioid receptor mu 1 (OPRM1)
  • Alt name
  • Alt name
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • GenBank ID
    NM_000914.5 Gene ID 4988
  • Entrez Gene
    OPRM1 (a.k.a. LMOR, M-OR-1, MOP, MOR, MOR1, OPRM)
  • Promoter hsyn
  • Tags / Fusion Proteins
    • FLAG (N terminal on insert)
    • T2A (N terminal on insert)
    • mCherry (N terminal on insert)

Cloning Information

  • Cloning method Unknown
  • 5′ sequencing primer GACTCAGCGCTGCCTCAGTCTG
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Vector Builder
  • Articles Citing this Plasmid

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pAAV-Syn1-FLEX-mCh-T2A-FLAG-hMOR-WPRE was a gift from Matthew Banghart (Addgene plasmid # 166970 ; ; RRID:Addgene_166970)
  • For your References section:

    Neural basis of opioid-induced respiratory depression and its rescue. Liu S, Kim DI, Oh TG, Pao GM, Kim JH, Palmiter RD, Banghart MR, Lee KF, Evans RM, Han S. Proc Natl Acad Sci U S A. 2021 Jun 8;118(23). pii: 2022134118. doi: 10.1073/pnas.2022134118. 10.1073/pnas.2022134118 PubMed 34074761
