(Plasmid #177190)


Item Catalog # Description Quantity Price (USD)
Plasmid 177190 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    Low Copy


  • Gene/Insert name
    HyPro enzyme
  • Alt name
    APEX2 - DIG10.3 fusion protein
  • Species
  • Promoter T7

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer TAATACGACTCACTATAGGG
  • 3′ sequencing primer GCTAGTTATTGCTCAGCGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

E. coli codon-optimized versions of APEX2 and DIG10.3 genes from and, respectively, were fused in frame via the (GGGGS)3 linker sequence.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pML433 was a gift from Eugene Makeyev (Addgene plasmid # 177190 ; ; RRID:Addgene_177190)
  • For your References section:

    Hybridization-proximity labeling reveals spatially ordered interactions of nuclear RNA compartments. Yap K, Chung TH, Makeyev EV. Mol Cell. 2021 Nov 2. pii: S1097-2765(21)00838-8. doi: 10.1016/j.molcel.2021.10.009. 10.1016/j.molcel.2021.10.009 PubMed 34741808
