(Plasmid #31317)


Full plasmid sequence is not available for this item.


Item Catalog # Description Quantity Price (USD)
Plasmid 31317 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 5400
  • Vector type
    Mammalian Expression
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • Entrez Gene
    TOPBP1 (a.k.a. Dpb11, TOP2BP1)
  • Tags / Fusion Proteins
    • LacR (N terminal on insert)
    • FLAG (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CMV-F
  • 3′ sequencing primer SP6
  • (Common Sequencing Primers)

Resource Information

  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3-LacR-TopBP1 was a gift from Aziz Sancar (Addgene plasmid # 31317 ; ; RRID:Addgene_31317)
  • For your References section:

    Tethering DNA Damage Checkpoint Mediator Proteins Topoisomerase II{beta}-binding Protein 1 (TopBP1) and Claspin to DNA Activates Ataxia-Telangiectasia Mutated and RAD3-related (ATR) Phosphorylation of Checkpoint Kinase 1 (Chk1). Lindsey-Boltz LA, Sancar A. J Biol Chem. 2011 Jun 3. 286(22):19229-36. 10.1074/jbc.M111.237958 PubMed 21502314
