pEGFP Cep170 (Nigg PID200)
(Plasmid #41150)


Item Catalog # Description Quantity Price (USD)
Plasmid 41150 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
    pEGFP-T7/C1 (modified pEGFP-C1)
  • Backbone manufacturer
    Modified from Clontech
  • Backbone size w/o insert (bp) 4700
  • Total vector size (bp) 9700
  • Modifications to backbone
    From pEGFP-C1: T7 promoter inserted into the vector NheI site
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
    Centrosomal protein 170kDa
  • Alt name
  • Alt name
  • Species
    H. sapiens (human)
  • Insert Size (bp)
  • GenBank ID
  • Entrez Gene
    CEP170 (a.k.a. FAM68A, KAB, KIAA0470)
  • Promoter CMV, T7
  • Tag / Fusion Protein
    • eGFP (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI\SalI (destroyed during cloning)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer EGFP-C; CMV-F
  • 3′ sequencing primer SV40-pA-R
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    KIAA0470 cDNA obtained from the Kazusa DNA Research Institute
  • Articles Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The KIAA0470 cDNA was obtained from the Kazusa DNA Research Institute. It was subcloned into pT7-EGFP-C1 (modified from pEGFP-C1; BD Biosciences Clontech), after removing the ATG. Specifically, a 5kb SalI-SnaBI (Klenow blunted) fragment from pBS/KIAA0470Δ5'UTR was ligated into pT7-EGFP-C1 (Nigg COM81) digested with XhoI (Klenow blunted). The 3' XhoI site was recreated.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pEGFP Cep170 (Nigg PID200) was a gift from Erich Nigg (Addgene plasmid # 41150 ; ; RRID:Addgene_41150)
  • For your References section:

    The forkhead-associated domain protein Cep170 interacts with Polo-like kinase 1 and serves as a marker for mature centrioles. Guarguaglini G, Duncan PI, Stierhof YD, Holmstrom T, Duensing S, Nigg EA. Mol Biol Cell. 2005 Mar;16(3):1095-107. Epub 2004 Dec 22. 10.1091/mbc.e04-10-0939 PubMed 15616186
