pTagRFP675-N1
(Plasmid #44275)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 44275 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pN1
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3998
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    TagRFP675
  • Species
    Synthetic
  • Insert Size (bp)
    717
  • Mutation
    M41Q/F80W/S143N/L147M/S158N/D159Y/N173S
  • Promoter CMV

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site NotI (destroyed during cloning)
  • 5′ sequencing primer ggtaggcgtgtacggtgggag
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTagRFP675-N1 was a gift from Vladislav Verkhusha (Addgene plasmid # 44275 ; http://n2t.net/addgene:44275 ; RRID:Addgene_44275)
  • For your References section:

    Extended Stokes shift in fluorescent proteins: chromophore-protein interactions in a near-infrared TagRFP675 variant. Piatkevich KD, Malashkevich VN, Morozova KS, Nemkovich NA, Almo SC, Verkhusha VV. Sci Rep. 2013;3:1847. doi: 10.1038/srep01847. 10.1038/srep01847 PubMed 23677204
