(Plasmid #45446)


Item Catalog # Description Quantity Price (USD)
Plasmid 45446 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone manufacturer
  • Backbone size w/o insert (bp) 4006
  • Total vector size (bp) 8996
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number


  • Gene/Insert name
  • Alt name
  • Alt name
  • Alt name
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
  • Mutation
    EGFP inserted after the predicted signal peptide cleavage site (after amino acid residue 26)
  • GenBank ID
  • Entrez Gene
    Grin1 (a.k.a. GluN1, NMDAR1, NR1)
  • Promoter CMV
  • Tag / Fusion Protein
    • EGFP (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer T7; chim-int-F (TCTTACTGACATCCACTTTGCC)
  • 3′ sequencing primer EBV-rev
  • (Common Sequencing Primers)

Resource Information

  • Supplemental Documents
  • A portion of this plasmid was derived from a plasmid made by
    Rat NMDA receptor genes originally cloned by Shigetada Nakanishi (PMID: 1834949)
  • Articles Citing this Plasmid

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCI-EGFP-NR1 wt was a gift from Andres Barria & Robert Malinow (Addgene plasmid # 45446 ; ; RRID:Addgene_45446)
  • For your References section:

    Subunit-specific NMDA receptor trafficking to synapses. Barria A, Malinow R. Neuron. 2002 Jul 18;35(2):345-53. 10.1016/S0896-6273(02)00776-6 PubMed 12160751
