pCAG-GBP1-10gly-Gal4DBD
(Plasmid #49438)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 49438 Standard format: Plasmid sent in bacteria as agar stab 1 $75

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pCAG-GFP
  • Backbone size w/o insert (bp) 4823
  • Total vector size (bp) 5666
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GBP1-Gal4 DNA binding domain fusion protein
  • Alt name
    GBP1-10gly-Gal4DBD
  • Alt name
    DBDG
  • Species
    Synthetic
  • Insert Size (bp)
    843
  • Mutation
    C98S (to increase protein solubility), Q3D
  • Promoter CAG

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site AgeI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer GGACTTCCTTTGTCCCAAATCTG
  • 3′ sequencing primer TAGCCAGAAGTCAGATGCTC
  • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    GBP1 protein sequence was obtained from PDB website, 3K1K entry.
  • Terms and Licenses
  • Industry Terms
    • Not Available to Industry
  • Article Citing this Plasmid

Depositor Comments

The GBP1 used differs from the PDB GBP1 by two amino acids. One is Q3D at a site away from the GFP binding pocket and not expected to affect GFP binding. The second was a C98S mutation to enhance protein solubility.

Kirchhofer, A. et al. (2010). Modulation of protein properties in living cells using nanobodies. Nat. Struct. Mol. Biol. 17, 133–138.

Tang J.C. et al. (2013). A nanobody-based system using fluorescent proteins as scaffolds for cell-specific gene manipulation. Cell. 2013 Aug 15;154(4):928-39.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCAG-GBP1-10gly-Gal4DBD was a gift from Connie Cepko (Addgene plasmid # 49438 ; http://n2t.net/addgene:49438 ; RRID:Addgene_49438)
  • For your References section:

    A nanobody-based system using fluorescent proteins as scaffolds for cell-specific gene manipulation. Tang JC, Szikra T, Kozorovitskiy Y, Teixiera M, Sabatini BL, Roska B, Cepko CL. Cell. 2013 Aug 15;154(4):928-39. doi: 10.1016/j.cell.2013.07.021. 10.1016/j.cell.2013.07.021 PubMed 23953120
