(Plasmid #57202)


Item Catalog # Description Quantity Price (USD)
Plasmid 57202 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Backbone size w/o insert (bp) 4750
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
  • Growth Strain(s)
  • Copy number
    High Copy


  • Gene/Insert name
  • Alt name
  • Species
    H. sapiens (human)
  • Entrez Gene
  • Promoter CMV
  • Tag / Fusion Protein
    • PA-mCherry1

Cloning Information

Resource Information

Terms and Licenses

  • Zeocin® is an InvivoGen trademark.

Depositor Comments

. Excitation = 400 / 504; Emission = 515 / 517

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    PA-mCherry1-Vimentin-7 was a gift from Michael Davidson (Addgene plasmid # 57202 ; ; RRID:Addgene_57202)
  • For your References section:

    Confined activation and subdiffractive localization enables whole-cell PALM with genetically expressed probes. York AG, Ghitani A, Vaziri A, Davidson MW, Shroff H. Nat Methods. 2011 Apr;8(4):327-33. doi: 10.1038/nmeth.1571. Epub 2011 Feb 13. 10.1038/nmeth.1571 PubMed 21317909
