AIMTOR A757
(Plasmid #140829)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 140829 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    YEN
  • Backbone manufacturer
    Goyet et al 2016, Scientific Reports, 6:28231. DOI: 10.1038/srep28231 and Komatsu, N et al.Molecular biology of the cell 22, 464
  • Backbone size w/o insert (bp) 6529
  • Total vector size (bp) 6583
  • Modifications to backbone
    The plasmid coding for YEN contains a cytoplasmic Extracellular signal-regulated Kinase Activity Reporter (EKAR) boxed between BRET-compatible entities (Ypet and Nanoluciferase ), pEevee-Ypet-EKARcyto-Nluc. It was designed from the optimized backbone structure of a FRET biosensor with the 116-amino-acid (SAGG)29-repeats linker (pEKAREV(3560)NES pEevee) constructed by Komatsu and colleagues (Komatsu, N. et al. Development of an optimized backbone of FRET biosensors for kinases and GTPases. Molecular biology of the cell 22, 4647–4656, doi: 10.1091/mbc.E11-01-0072, 2011). The ECFP-coding sequence, removed by NotI/XbaI digestion, was replaced by the Nanoluciferase-coding sequence, amplified by PCR (from pNanoLuc3.2 NFKB RE) and inserted into the NotI/XbaI sites by an Infusion reaction (Clontech), The YEN plasmid served then as a backbone plasmid to construct the plasmid AIMTOR A757. To this end, we removed the sequence coding for the ERK sensor site by a BspeI/NotI restriction digest. Following a ligation with a cohesive double strand pre-annealed oligonucleotides encoding the A757 mutated sensor peptide derived from human UlK1 protein, we obtained the plasmid AIMTOR A757
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    AIMTOR A757
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    34
  • Mutation
    The insert comprises only a small sequence of human Ulk1 encoding for a 9 aminoacids peptide, conserved 100% in mouse Ulk1. The original serine residue phosphorylable by mTOR in this peptide (position 757 in mouse Ulk1) has been mutated to a non-phosphoylable Alanine residue to serve as a negative control for BRET experiments.
  • GenBank ID
    NM_003565.4
  • Entrez Gene
    ULK1 (a.k.a. ATG1, ATG1A, UNC51, Unc51.1, hATG1)
  • Tag / Fusion Protein
    • NES Nuclear export signal (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BspEI (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer CCACTACCTGAGCTACCAG
  • 3′ sequencing primer GCCAGAAGTCAGATGCTCA
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    AIMTOR A757 was a gift from Anne Bonnieu (Addgene plasmid # 140829 ; http://n2t.net/addgene:140829 ; RRID:Addgene_140829)
  • For your References section:

    AIMTOR, a BRET biosensor for live imaging, reveals subcellular mTOR signaling and dysfunctions. Bouquier N, Moutin E, Tintignac LA, Reverbel A, Jublanc E, Sinnreich M, Chastagnier Y, Averous J, Fafournoux P, Verpelli C, Boeckers T, Carnac G, Perroy J, Ollendorff V. BMC Biol. 2020 Jul 3;18(1):81. doi: 10.1186/s12915-020-00790-8. 10.1186/s12915-020-00790-8 PubMed 32620110
