PurposeOptogenetic tool for blue-light inhibition and red-light excitation of neurons
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||154945||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 4359
Vector typeMammalian Expression, AAV
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Growth Strain(s)NEB Stable
Copy numberHigh Copy
Insert Size (bp)3273
- Promoter human synapsin
/ Fusion Protein
- soma-targeting motif from Kv2.1 channel (C terminal on insert)
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site HindIII (not destroyed)
- 5′ sequencing primer GACTCAGCGCTGCCTCAGTCTG
- 3′ sequencing primer TGTTGCTCCTTTTACGCTATG (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
The insert contains the fluorescence tag mCerulean3 in between the 2 channelrhodopsins (C-terminal of GtACR2). Please note that the Addgene verified sequence identified differences in the 3' ITR sequence compared to the depositor's reference sequence. These differences do not affect plasmid function. These Please visit https://www.biorxiv.org/content/10.1101/2020.07.15.204347v1 for bioRxiv preprint.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:hSyn-somBiPOLES-mCerulean was a gift from Simon Wiegert (Addgene plasmid # 154945 ; http://n2t.net/addgene:154945 ; RRID:Addgene_154945)
For your References section:BiPOLES is an optogenetic tool developed for bidirectional dual-color control of neurons. Vierock J, Rodriguez-Rozada S, Dieter A, Pieper F, Sims R, Tenedini F, Bergs ACF, Bendifallah I, Zhou F, Zeitzschel N, Ahlbeck J, Augustin S, Sauter K, Papagiakoumou E, Gottschalk A, Soba P, Emiliani V, Engel AK, Hegemann P, Wiegert JS. Nat Commun. 2021 Jul 26;12(1):4527. doi: 10.1038/s41467-021-24759-5. 10.1038/s41467-021-24759-5 PubMed 34312384
