pUCBB-eGFP
(Plasmid #32548)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 32548 Standard format: Plasmid sent in bacteria as agar stab 1 $65

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pUCBB
  • Backbone manufacturer
    Schmidt-Dannert Lab
  • Backbone size w/o insert (bp) 2395
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    eGFP
  • Insert Size (bp)
    719
  • Entrez Gene
    eGFP (a.k.a. pPRS3a_01)
  • Promoter Consitutive lac
  • Tag / Fusion Protein
    • His (C terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site NsiI (not destroyed)
  • 5′ sequencing primer pBBinF (CATCCTGAACTTATCTAGACC)
  • 3′ sequencing primer pBBinR (GCAGGTCCTGAAGTTAACTAG)
  • (Common Sequencing Primers)

Resource Information

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pUCBB-eGFP was a gift from Claudia Schmidt-dannert (Addgene plasmid # 32548 ; http://n2t.net/addgene:32548 ; RRID:Addgene_32548)
  • For your References section:

    Optimized compatible set of BioBrick vectors for metabolic pathway engineering. Vick JE, Johnson ET, Choudhary S, Bloch SE, Lopez-Gallego F, Srivastava P, Tikh IB, Wawrzyn GT, Schmidt-Dannert C. Appl Microbiol Biotechnol. 2011 Dec;92(6):1275-86. Epub 2011 Oct 28. 10.1007/s00253-011-3633-4 PubMed 22033566
