PurposeInserts a puromycin resistance gene and a VSG117 gene into the VSG221 expression site of T.brucei downstream of the expression site promoter.
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||59732||Standard format: Plasmid sent in bacteria as agar stab||1||$85|
This material is available to academics and nonprofits only.
- Backbone size w/o insert (bp) 3045
- Total vector size (bp) 8476
Vector typeFor homologous recombination into VSG221 expression site in T. brucei
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Gene/Insert nameVSG117 flanked upstream and downstream by sequences homologous to the VSG221 expression site
SpeciesT. brucei Lister 427
Insert Size (bp)5431
- Cloning method Restriction Enzyme
- 5′ cloning site NotI (not destroyed)
- 3′ cloning site XhoI (not destroyed)
- 5′ sequencing primer aacaaaagctggagctccac (Common Sequencing Primers)
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:p221- purVSG117UTR was a gift from Gloria Rudenko (Addgene plasmid # 59732 ; http://n2t.net/addgene:59732 ; RRID:Addgene_59732)
For your References section:Blocking variant surface glycoprotein synthesis in Trypanosoma brucei triggers a general arrest in translation initiation. Smith TK, Vasileva N, Gluenz E, Terry S, Portman N, Kramer S, Carrington M, Michaeli S, Gull K, Rudenko G. PLoS One. 2009 Oct 26;4(10):e7532. doi: 10.1371/journal.pone.0007532. 10.1371/journal.pone.0007532 PubMed 19855834
